Engine
- Model: OM 926
- Maximum Power, KW: 180 Kw @ 2200 rpm
- Maximum Torque, Nm: 850 Nm @ 1200 - 1600 rpm
- No. of Cylinders, Displacement(CC): 6, 7200 cc
- Emission Compliance: Bharat Stage VI
Features
Specifications
» Gearbox Model & Type: Improved G85, 6F+1R, Mechanical, Synchromesh Gears
» Clutch Type: Single Dry Plate, Hydraulic Control
» Clutch Diameter(mm): 395, 4 mm
» Front Axle Model, Type: IF 7.0
» Rear Axle Model, Type: RA1:IR440-11 & RA2: IT- 10
» Rear Axle Ratio*: 5.875
| Wheel Base(mm): | 5775 | 6375 | 6375 |
| Cabin: | Sleeper | Sleeper | Compact Sleeper |
| Loading Span(ft)/Loadbody cpc (Cu.m): | 26 ft | 28 ft | 32 ft |
| Overall Length(mm): | 10492 | 11092 | 11992 |
| Overall Width(mm): | 2490 | 2490 | 2490 |
| Overall Height(mm)(CBC): | 2960 | 2960 | 2960 |
| Front Overhang(mm): | 1485 | 1485 | 1485 |
| Rear Overhang(mm): | 2557 | 2557 | 3457 |
| Minimum Ground Clearance: | 233 | 233 | 233 |
» Gross Vehicle Weight: 35,000 kgs (Tubeless tyres)/34,920 kgs (Radial Tyres)
» Frame Section (DxWxT) (mm): 286 x 70 x 8
» Front Suspension: Parabolic Type Leaf Spring with 2 Hydraulic Shock Absorbers
» Rear Suspension: Balancer Type Semi-Elliptical Leaf Spring
» Anti Roll Bar: [Front: Standard Rear applicable for: High Centre of Gravity (HCG)],
[Front: Standard Rear applicable for: Hazards Goods Pack (HGP) & High Centre of Gravity (HCG),
[Front: Standard Rear applicable for: High Centre of Gravity (HCG)]
» Service Brake: Pneumatic, Foot Operated, Dual Line with ABS
» Parking Brake: Pneumatically Operated Hand Control Valve
» Front Axle Brake: Ø 410 drum
» Rear Axle Brake: Ø 410 drum
» Tyre Size: Radial Tyres (Rib & Lug Pattern - 11R20 or 295/90R20),
Tubeless Tyres (All Wheel Pattern - 295/80R22.5),
Tubeless Tyres (Rib & Lug Pattern - 295/80R22.5)
» Steering Type: Hydraulic Power assisted
» Cabin: Sleeper Cabin with Berth, Tiltable
» Fuel Tank/Filling Capacity*: Standard - 380L/355L ; HGP tanker - 200L/185L
» Adblue Tank/Filling Capacity: 60L/51L
» Voltage: 24V
» Battery Capacity: 120Ah (Std)/130Ah (For HAP)
» Maximum Gradeability %: 18.5%
» Maximum Geared Speed: 80 kmph (std)/60 kmph (POL Tanker)
» Turning Circle Diameter(TCD)*: 21.6m, 23.7m, 23.7m
