Engine
- Model: 4D34i
- Maximum Power, KW: 110 Kw @ 2500 rpm
- Maximum Torque, Nm: 460 Nm @ 1500 rpm
- No. of Cylinders, Displacement(CC): 4, 3900 cc
- Emission Compliance: Bharat Stage VI
Features
Specifications
» Gearbox Model & Type: Improved G85, 6F+1R, Mechanical, Synchromesh Gears
» Clutch Type: Single Dry Plate, Hydraulic Actuated
» Clutch Diameter(mm): 362
» Front Axle Model, Type: IF 5.0
» Rear Axle Model, Type: DANA S 145
» Rear Axle Ratio*: [6.33 S, 4.56 O],[6.33 S, 4.56 O],[4.56 S, 6.33 HAP /Optional],[4.56 S, 6.33 HAP/Optional], [4.56 S, 6.33 HAP /Optional]
| Wheel Base: | 3360 | 3760 | 4250 | 4800 | 5050 |
| Cabin: | Day | Day | Day | Day | Day |
| Loadbody Length(Cu.m): | 14.6ft | 17ft | 20ft | 22ft | 24ft |
| Overall Length(mm): | 6380 | 7075 | 8030 | 8580 | 9295 |
| Overall Width(mm): | 2135 | 2135 | 2135 | 2135 | 2135 |
| Overall Height(mm): | 2480/2475 | 2480/2475 | 2480/2475 | 2480/2475 | 2480/2475 |
| Front Overhang(mm): | 1275 | 1275 | 1275 | 1275 | 1275 |
| Rear Overhang(mm): | 1745 | 2040 | 2505 | 2505 | 2970 |
| Minimum Ground Clearance: | 225/220 | 225/220 | 225/220 | 225/220 | 225/220 |
» Gross Vehicle Weight: 14,050 Kgs/14,500 Kgs (Only tubeless tyre)
» Frame Section (DxWxT) (mm): 230 x 80 x 7
» Front Suspension: Multileaf Spring
» Rear Suspension: Multileaf Spring
» Anti Roll Bar: Optional (front & rear)
» Service Brake: Pneumatic, Foot Operated, Dual Line with ABS
» Parking Brake: Spring Actuated with Hand Brake Valve @ Cab
» Front Axle Brake: Ø 360 drum
» Rear Axle Brake: Ø 360 drum
» Tyre Size: Radial Tyres (8.25R20), Tubeless Tyres (255/70R22.5)
» Steering Type: Hydraulic Power assisted
» Cabin: A/C Day Cabin, Tiltable
» Fuel Tank/Filling Capacity*: 171L/160L, 215L/200L, 215L/200L, 215L/200L, 215L/200L
» Adblue Tank/Filling Capacity: 43L/36L
» Voltage: 24V
» Battery Capacity: 75Ah/100AH (HAP)
» Maximum Gradeability %: 24.90%, 19.80%, 19.80%
» Maximum Geared Speed: 70 kmph (for RT), 80 kmph (for TT)
» Turning Circle Diameter(TCD)*: 13.4m, 13.8m, 15.7m 17.6m, 19.7m
