Engine
- Model: DE175BS4
- Maximum Power, KW: 210 Kw @ 2200 rpm
- Maximum Torque, Nm: 1100 Nm @ 1200 - 1600 rpm
- No. of Cylinders, Displacement(CC): 6, 7200 cc
- Emission Compliance: Bharat Stage VI
Features
Specifications
» Gearbox Model & Type: G 131, 9F+1R, Mechanical, Synchromesh Gears
» Clutch Type: Single Dry Plate, Hydraulic Control
» Clutch Diameter(mm): 395, 4 mm
» Front Axle Model, Type: IF 7.0
» Rear Axle Model, Type: RA 1:IR440-11 & RA2: IT- 10
» Rear Axle Ratio*: 4.3
| Wheel Base(mm): | 6575 |
| Cabin: | Sleeper |
| Loading Span(ft)/Loadbody cpc (Cu.m): | 28ft |
| Overall Length(mm): | 10992 |
| Overall Width(mm): | 2490 |
| Overall Height(mm)(CBC): | 2939 |
| Front Overhang(mm): | 1485 |
| Rear Overhang(mm): | 2257 |
| Minimum Ground Clearance(mm): | 222 |
» Gross Vehicle Weight: 42,000 kgs (Tubeless & 295/90R20)/41,920 kgs (11R20)
» Frame Section (DxWxT) (mm): 286 x 70 x 8
» Front Suspension: Parabolic Type Leaf Spring with 2 Hydraulic Shock Absorbers
» Rear Suspension: Balancer Type Semi-Elliptical Leaf Spring
» Anti Roll Bar: Standard on Front Axle
» Service Brake: Pneumatic, Foot Operated, Dual Line with ABS
» Parking Brake: Pneumatically Operated Hand Control Valve
» Front Axle Brake: Ø 410 drum
» Rear Axle Brake: Ø 410 drum
» Tyre Size: Radial Tyres (Rib & Lug Pattern - 11R20 or 295/90R20)
Tubeless Tyres (All Wheel Pattern - 295/80R22.5)
Tubeless Tyres (Rib & Lug Pattern - 295/80R22.5)
» Steering Type: Hydraulic Power assisted
» Cabin: Sleeper Cabin with Berth, Tiltable
» Fuel Tank/Filling Capacity*: Standard - 330L/310L
» Adblue Tank/Filling Capacity: 60L/ 51L
» Voltage: 24V
» Battery Capacity: 120Ah
» Maximum Gradeability %: 29%
» Maximum Geared Speed: 80 kmph(Standard)
» Turning Circle Diameter(TCD)*: 24m
