Engine
- Model: OM 926
- Maximum Power, KW: 180 Kw @ 2200 rpm
- Maximum Torque, Nm: 850 Nm @ 1200 - 1600 rpm
- No. of Cylinders, Displacement(CC): 6, 7200 cc
- Emission Compliance: Bharat Stage VI
Features
Specifications
» Gearbox Model & Type: Improved G85, 6F+1R, Mechanical, Synchromesh Gears
» Clutch Type: Single Dry Plate, Hydraulic Control
» Clutch Diameter(mm): 395, 3.5 mm
» Front Axle Model, Type: IF 7.0
» Rear Axle Model, Type: RA: IR440-11
» Rear Axle Ratio*: 5.875
| Wheel Base(mm): | 3600 |
| Cabin: | Day cabin with foldable berth |
| Loading Span(ft)/Loadbody cpc (Cu.m): | 10.5 Cu.m Box |
| Overall Length(mm): | 6185 |
| Overall Width(mm): | 2490 |
| Overall Height(mm)(CBC): | 2960 |
| Front Overhang(mm): | 1485 |
| Rear Overhang(mm): | 1100 |
| Minimum Ground Clearance(mm): | 265 |
» Gross Vehicle Weight: 18,500 kgs (Nylon Tyre)
» Frame Section (DxWxT) (mm): 288 x 70 x 9
» Front Suspension: Parabolic Type Leaf Spring with 2 Hydraulic Shock Absorbers
» Rear Suspension: Semi-elliptical Leaf Spring
» Anti roll Bar: Front: Standard, Rear: Standard
» Service Brake: Pneumatic Foot Operated, Dual Line with ABS
» Parking Brake: Pneumatically Operated Hand Control Valve
» Front Axle Brake: Ø 410 drum
» Rear Axle Brake: Ø 410 drum
» Tyres: Nylon Tyre (11x20)
» Steering Type: Hydraulic Power assisted
» Cabin: Day Cabin, Tiltable
» Fuel Tank/Filling Capacity*: 215L/200L
» Adblue Tank/Filling Capacity: 43L/36L
» Voltage: 24V
» Battery Capacity: 120Ah (Std)/130Ah (For HAP)
» Maximum Gradeability %: 38%
» Maximum Geared Speed: 60 kmph
» Turning Circle Diameter(TCD)*: 13.5m
