Engine
- Model: OM 926
- Maximum Power, KW: 180 Kw
- Maximum Torque, Nm: 850 Nm
- No. of Cylinders, Displacement(CC): 6, 7200 cc
- Emission Compliance: Bharat Stage VI
Features
Specifications
» Gearbox Model & Type: G 131, 9F + 1R, Mechanical, Synchromesh Gears
» Clutch Type: Single Dry Plate, Hydraulic Control
» Clutch Diameter(mm): 395, 3.5 mm
» Front Axle Model, Type: IF 7.0
» Rear Axle Model, Type: RA1: IRT 390-11, RA2: IRT 390-11
» Rear Axle Ratio*: 5.375
| Wheel Base(mm): | 4275 |
| Cabin: | Day with Foldable Berth |
| Loading Span(ft)/Loadbody cpc (Cu.m): | 16 Cu.m Box |
| Overall Length(mm): | 7185/7485 (RMC) |
| Overall Width(mm): | 2490 |
| Overall Height(mm)(CBC): | 2955 |
| Front Overhang(mm): | 1485 |
| Rear Overhang(mm): | 750/1050 (RMC) |
| Minimum Ground Clearance(mm): | 290 |
» Gross Vehicle Weight: 28,000 kgs (Radial Tyre/Nylon Tyre) 27,600 kgs (Mining Tyre)
» Frame Section (DxWxT) (mm): 288 x 70 x 9
» Front Suspension: Parabolic Type Leaf Spring with 2 Hydraulic Shock Absorbers
» Rear Suspension: Bogie Suspension
» Anti Roll Bar: Front: Standard; Rear: Standard(RA2)
» Service Brake: Pneumatic Foot Operated, Dual Line with ABS
» Parking Brake: Pneumatically Operated Hand Control Valve
» Front Axle Brake: Ø 410 drum
» Rear Axle Brake: Ø 410 drum
» Tyre Size: Radial Tyres (11R20), Nylon Tyre (11x20), Mining Tyre (11 x 20 mine)
» Steering Type: Hydraulic Power assisted
» Cabin: Day Cabin, Tiltable
» Fuel Tank/Filling Capacity*: 215L/200L
» Adblue Tank/Filling Capacity: 43L/36L
» Voltage: 24V
» Battery Capacity: 120Ah (Std)/130Ah (For HAP)
» Maximum Gradeability %: 43.3%
» Maximum Geared Speed: 60 kmph
» Turning Circle Diameter(TCD)*: 15.5m
