Sri Harsha Trucking

2828CH

Engine

Features

Specifications

ยป Gearbox Model & Type: G 131, 9F + 1R, Mechanical, Synchromesh Gears

ยป Clutch Type:ย Single Dry Plate, Hydraulic Control

ยป Clutch Diameter(mm):ย 430, 4.5 mm

ยป Front Axle Model, Type: IF 7.0

ยป Rear Axle Model, Type:ย RA1: MT 36 610, RA2: MT 36 610 Hub Reduction

ยป Rear Axle Ratio*:ย 5.39

Wheel Base(mm):4275
Cabin:Day with Foldable Berth
Loading Span(ft)/Loadbody cpc (Cu.m):16 Cu.m Scoop and Box
Overall Length(mm):7185
Overall Width(mm):2490
Overall Height(mm)(CBC):2995
Front Overhang(mm):1485
Rear Overhang(mm):750
Minimum Ground Clearance(mm):331

ย

ยป Gross Vehicle Weight: 27,600 kgs (Mining Tyre)

ยป Frame Section (DxWxT) (mm): 288 x 70 x 9

ยป Front Suspension:ย Parabolic Type Leaf Spring with 2 Hydraulic Shock Absorbers

ยป Rear Suspension:ย Bogie Suspension

ยป Anti Roll Bar:ย Front: Standard; Rear: Standard(RA2)

ยป Service Brake:ย Pneumatic Foot Operated, Dual Line with ABS

ยป Parking Brake:ย Pneumatically Operated Hand Control Valve

ยป Front Axle Brake:ย ร˜ 410 drum

ยป Rear Axle Brake:ย ร˜ 410 drum

ยป Tyre Size:ย Mining Tyre (11x20 mine)

ยป Fuel Tank/Filling Capacity*: 215L/200L

ยป Adblue Tank/Filling Capacity:ย 43L/36L

ยป Voltage:ย 24V

ยป Battery Capacity:ย 120Ah

ยป Maximum Gradeability %: 60.6%

ยป Maximum Geared Speed:ย 60 kmph

ยป Turning Circle Diameter(TCD)*:ย 16.2m
